Automatic H Beam Welding Line , Corrugated Web Beam Welding Machine

Friendship Machinery Co., Ltd
Contact Now

Automatic H Beam Welding Line , Corrugated Web Beam Welding Machine

Brand Name : FRIENDSHIP MACHINERY

Model Number : CW

Certification : CE, ISO

Place of Origin : CHINA

MOQ : 1

Payment Terms : T/T, L/C

Supply Ability : 30 sets per month

Delivery Time : 20 working days

Packaging Details : Wooden box

Welding wire : 1.0mm/ 1.2mm

Web width : 200-1500mm

Flange height : 150-500mm

Equipment name : Corrugaed web welding machine

Voltage : 380V, 50HZ

MIG welder : Panasonic 350A

Contact Now

Automatic H Beam Welding Line



Corrugated Web Beam Welding Machine



Corrugaed Panel Welding Machine





Name Specifications



Corrugated beam information

Flange width: 150-500mm
  Flange thickness: 2.8-32mm
  Corrugated web height: 240-1500mm
  Corrugated web thickness: 1.5-8mm
Effective welding length 4-12000mm
Welded material Carbon steel
Welding carriage driven method Gear rack and servo motor
Welding torch movement method (up and down) Motorized, ball screw
Welding torch movement method (front and back) Motorized, ball screw
Welding wire diameter 1.0mm or 1.2mm
Welding speed 500-1500mm/min (adjustable)
Return speed 0-10000mm/min (adjustable)
Welding seam tracking inspect Laser tracking
Welding method MIG welding
Main machine power 18KW



Automatic H Beam Welding Line , Corrugated Web Beam Welding Machine



Automatic H Beam Welding Line , Corrugated Web Beam Welding Machine
